LI-ION CORDLESS TOOLS

Heavy duty impact block:
for higher torque.

Led worklight:
an optimum Whole frame motor:
view of the avoids friction
workplace. between rotor and
stator, increasing
durability.

Brushless DC electric motors have
permanent magnets which rotate Double seal ring:
around a fi xed armature, an electronic ensures no oil-leakage.
controller replaces the brush/
commutator assembly of the brushed
DC motor.

They offer several advantages: high
torque to weight ratio, more torque per
watt (increased effi ciency), reduced
noise, longer lifetime, and reduced
maintenance operation.

CT22021HX-2 TB CT22021HX
CT22021HX-4 TB

Rated voltage 20 V Max. Rated voltage 20 V Max.
Battery capacity 2 Ah / 4 Ah Compatible batteries CAB202014X, CAB202014XE,
Charging time 30 min / 60 min CAB202013X, CAB202013XE
No-load speed 0-2100 min -1 No-load speed 0-2100 min -1
Impact rate 3200 min -1 Impact rate 3200 min -1
Max. torque 300 Nm Max. torque 300 Nm
Tool holder type 1/4" hexagonal Tool holder type 1/4" hexagonal
Max bolt diameter M12 Max bolt diameter M12
Max nut diameter M22 Max nut diameter M22
Weight 1,52 kg / 1,79 kg Weight 1,13 kg

19
